This Shut Up Noise (SUN) Noise Gate includes 4 jacks to wire the pedal in 2, 3 or 4-wire method.
Wire it directly in front of the amp, or in the FX Loop, using the key input, for even more hum annihilation.
You can also use this noise gate in 4-wire even if your amp is not equipped with a FX loop. Just use the side jacks for detection as soon as possible and the top jacks after all your noisy pedal.
Go as soon as possible in your signal chain into the right side jack (Detection Input), from the left side jack (Detection output), go to all your noisy FX and/or amp input. Come back in the top right jack with your FX Loop send (Actual gate input) and get out of the top left jack to your time-based FX and your amp FX Return.
If you want other funky looks, have a look at our artist series edition.
Power consumption : 38mA
Voltage : 9VDC Center Negative
This pedal, must-have for some, no-need-at-all for other, may have only one know, but is not an easy one to get by. This article goes in details to explain you the what, why, how of it and it will definitely help you understand and decide if you need it, and if so, how you should and could use it. It's even a troubleshooting guide for your pedalboard, for all that matter!
Cette pédale, un essentiel pour certain, et un "pas besoin" pour d'autre, n'a peut-être qu'un seul bouton, mais elle n'est pas simple d'utilisation pour autant! Cet article vous permettra de comprendre le quoi, le pourquoi et le comment de la patente, et de voir si vous en avez besoin et si oui, comment l'utiliser. Vous pourrez même vous en servir comme guide diagnostic pour votre arrangement.
Pedal works amazingly, dead silent and very responsive! Happy to support fellow Canadian builders!
Thanks GUP Tech!
I've tried a few noise gates, Boss NS-2, ISP G string, etc ... For my needs this SUN is the best. Its fast and tracks very well, I can keep the dial very low and still not have to worry about squealing or unwanted noise. Internal switch toggles high sensitivity vs lower. I usually have lots of gain, so I set it high. A great pedal
Works well in 4CM on my Mark V, I'd be using 5 OD/Fuzz type pedals and this treats it very well haha. My favorite thing about this pedal aswell its one giant knob. The 200+$ gate pedal I had with 3 knobs is wackkkkk. The S.U.N beats all the gate pedals!! (for metal)
I didn't think I really needed a new gate, as I was using a Gstring and thought it worked ok for my needs. A friend turned me on to this pedal, and I'm super impressed. Very transparent, and I can set it to a fraction of where I had my Gstring. I didn't realize the tone suck I was actually getting. Well done.
I have owned a Guul for quite some time and have to say it is a much better unit product than the “Zewl” but this SUN is even better… I run 4 wire into my amp and this SUN really is a superior gate compared to it predecessor. I ran my gate at about 11:30 to keep my Diezel absolutely quiet now using the SUN I am able to run as low as 9:00 and have added sustain and control…. If you are thinking about buying this gate do so you wont be sorry…
